Information
Product Description:Allied Telesis AT-DNC10SP - network adapter - PCIe x4 - Gigabit Ethernet / 10 Gigabit SFP+ x 1 - TAA Compliant
Device Type:Network adapter
Form Factor:Plug-in card
Interface (Bus) Type:PCI Express x4
PCI Specification Revision:PCIe 3.0
Bus Voltage:3.3 V
Ports:Gigabit Ethernet / 10 Gigabit SFP+ x 1
Dimensions (WxDxH):3.6 in x 2.7 in x 0.5 in
Weight:2.75 oz
Data Link Protocol:GigE, 10 GigE
Data Transfer Rate:10 Gbps
Compliant Standards:IEEE 802.2, IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 801.1Qau
System Requirements:Windows 10, Microsoft Windows Server 2019
TAA Compliant:Yes
Device Type:Network adapter
Form Factor:Plug-in card
Interface (Bus) Type:PCI Express x4
PCI Specification Revision:PCIe 3.0
Bus Voltage:3.3 V
Ports:Gigabit Ethernet / 10 Gigabit SFP+ x 1
Connectivity Technology:Wired
Data Link Protocol:Gigabit Ethernet, 10 Gigabit Ethernet
Data Transfer Rate:10 Gbps
Remote Management Protocol:SNMP
Status Indicators:Link/activity
Features:Flow control, VLAN support, wake on LAN (WOL), IPv6 support, Quality of Service (QoS), Link Aggregation Control Protocol (LACP), PXE 2.1 support, Priority-Based Flow Control (PFC), failover protection, VLAN filtering, UEFI Secture Boot, VLAN Tagging, Enhanced transmission selection (ETS), Quantized Congestion Notification (QCN), Jumbo Frames support (up to 16348 bytes), ACPI 1.1 support
Compliant Standards:IEEE 802.2, IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 801.1Qau
Interfaces:1 x 1Gb Ethernet/10Gb Ethernet - SFP+
Included Accessories:Low-profile bracket
Compliant Standards:VCCI, FCC, RoHS, EN 55032 Class B, IEC 62368-1, UL 62368-1, EN 55035
TAA Compliant:Yes
Power Consumption Operational:2 Watt
OS Required:Windows 10, Microsoft Windows Server 2019
Width:3.6 in
Depth:2.7 in
Height:0.5 in
Weight:2.75 oz
Min Operating Temperature:32 °F
Max Operating Temperature:122 °F
Humidity Range Operating:5 - 90% (non-condensing)
COO:SINGAPORE
TAA compliance:Yes
